Fullriver FR Series
High-Frequency Smart Battery Charger
FR1-AGC
Fullriver FR Series
High-Frequency Smart Battery Charger
FR1-AGC
Display Units
Imperial
Metric
AC Input Voltage Range
100 - 230 VAC
AC Input Frequency
50/60 Hz
Nominal DC Output Voltage
Selectable
DC Output Connector
SB50 Adapter to Alligator Clips
Battery Type
Lead Acid (Wet / AGM / GEL), Lithium Ion
Enclosure
Self-Extinguishing ABS
Dimensions
13.5 x 7.0 x 3.9 in
Weight
7.0 lbs.
AC Input Voltage Range
100 - 230 VAC
AC Input Frequency
50/60 Hz
Nominal DC Output Voltage
Selectable
DC Output Connector
SB50 Adapter to Alligator Clips
Battery Type
Lead Acid (Wet / AGM / GEL), Lithium Ion
Enclosure
Self-Extinguishing ABS
Dimensions
343 x 178 x 99 mm
Weight
3.2 kg
DC Output Voltage (VDC)
This is a block of text. Double-click this text to edit it.
12V
16V
24V
28V
36V
42V
48V
Max DC Wattage
441 W
696 W
882 W
1015 W
1102 W
1200 W
1200 W
Max DC Amperage
30 A
30 A
30 A
25 A
25 A
20 A
20 A
Max DC Voltage
17.4V
23.2V
34.8V
40.6V
52.2V
60.9V
69.6V
Min DC Voltage
-6 volts of nominal setting
Max Interlock Amperage
2 Amps (on inductive load)
Battery Type
Lead-acid (Wet, AGM, GEL), Lithium-ion
Reverse Polarity
Electronic Protection
Short Circuit
Electronic Current Limit
Voltage / Current / 20Hr Rate
This is a block of text. Double-click this text to edit it.
CURRENT
20 HOUR RATE (Ah)
24V
This is a block of text. Double-click this text to edit it.
12V
MIN
MAX
12V / 16V
15 A
20 A
25 A
30 A
20 A
25 A
30 A
130
150
220
245
150
220
245
185
240
315
350
240
315
350
24V / 28V
15 A
20 A
25 A
30 A
20 A
25 A
30 A
130
150
220
245
150
220
245
185
240
315
350
240
315
350
36V
15 A
20 A
25 A
20 A
25 A
130
150
220
150
220
185
240
315
240
315
42V / 48V
15 A
20 A
20 A
130
150
150
185
240
240
AC Input
AC Input Voltage Range
-6 volts of nominal setting
AC Input Frequency
2 Amps (on inductive load)
Max AC Input Current
Lead-acid (Wet, AGM, GEL), Lithium-ion
AC Power Factor
Electronic Protection
General
Dimensions
13.5 x 7.0 x 3.9 in
343 x 178 x 99 mm
343 x 178 x 99 mm
Weight
7.0 lbs
3.2 kg
3.2 kg
AC Input Connector
IEC 320 C14 (AC Cord included)
DC Output Connector
SB50 Standard or 3/8” Ring Terminal
Operating Temperature
14°F - 113°F (-10°C - 45°C)
Enclosure
Self-Extinguishing ABS
Efficiency
> 90% @ Full Load, CEC Compliance (pending)
