Full Throttle Series
High-Performance AGM Battery
FT410L
Display Units
Imperial
Metric
Group Size
BTX30L [BCI]
Capacity
28 Ah
Reserve Capacity
48 min
10.1 min
CCA
410 Amps
Dimensions
6.50 x 6.93 x 5.67 in
Weight
22.92 lbs.
Group Size
BTX30L [BCI]
Capacity
28 Ah
Reserve Capacity
48 min
10.1 min
CCA
410 Amps
Dimensions
165 x 176 x 144 mm
Weight
10.4 kg
UPC# 810233030404
/
ASIN# B07SZ5B9CZ
Share this Battery
Electrical Specifications
Nominal Voltage
12V
C100
31 Ah
C20
28 Ah
C5
23 Ah
CCA
410 Amps
CA or MCA
530 Amps
PHCA
925 Amps
Internal Resistance
9.1 mΩ
Mechanical Specifications
Group Size
BTX30L
BTX30L
Terminal Type
M6 + TP26 (SAE)
Terminal Torque
3.3 - 4.8
40 - 57.5
4.5 - 6.5
Height (w/ terminal)
5.67
/
144
Height (case only)
4.92
/
125
Width
6.93
/
176
Length
6.50
/
165
Weight
22.92
/
10.4
Case Type
ABS Plastic
